Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control
Improve lighting efficiency and reduce energy consumption with the Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control, a professional-grade solution designed for commercial and industrial LED lighting systems. This sensor combines occupancy detection, daylight harvesting, and 0-10V dimming control to automatically adjust lighting levels based on space usage and available natural light.
Built for demanding environments, the sensor features an IP65-rated enclosure, making it suitable for warehouses, factories, manufacturing facilities, parking structures, gymnasiums, retail spaces, and other commercial applications. The unit operates on 12V-24V DC power and provides a 0-10V dimming output with up to 30mA sinking current for reliable LED fixture control.
Two lens options are available to accommodate different mounting heights. The L7 lens is optimized for low bay installations with mounting heights up to 13ft, while the L8 lens is designed for high bay applications with mounting heights up to 40ft. Both versions offer a maximum detection radius of 23ft.
For additional flexibility, users can select adjustable time delays of 10 seconds, 1 minute, 5 minutes, or 15 minutes. The integrated daylight harvesting function allows light-level settings of 300 lux, 500 lux, 800 lux, or disable mode, helping maximize energy savings without compromising visibility.
The sensor is engineered for reliable performance in harsh conditions, supporting operating temperatures from -4°F to 140°F (-20°C to 60°C) and humidity levels up to 95% RH.
Whether upgrading a warehouse, factory, commercial building, or industrial facility, the Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control delivers intelligent lighting automation, improved energy efficiency, and dependable long-term performance.
5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures
• This warranty policy is valid only for products sold in The United States of America.
• Products have been purchased directly from a LEDRadiant (sales) organization. • Proof of purchase is available for inspection by LEDRadiant. • Products have been properly installed and operated in accordance with the manufacturer’s instructions. • More than 10% of the LED chips are not properly working. • A LEDRadiant representative will have access to the defective Products. • If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems. • Shipping and Labor costs for installation of the Products are not covered under this warranty. This warranty is only sample: By LEDRadiant Save the environment, your children and the planet
615 North 21st Avenue, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com – www.ledradiant.com |
- Product Description
-
Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control
Improve lighting efficiency and reduce energy consumption with the Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control, a professional-grade solution designed for commercial and industrial LED lighting systems. This sensor combines occupancy detection, daylight harvesting, and 0-10V dimming control to automatically adjust lighting levels based on space usage and available natural light.
Built for demanding environments, the sensor features an IP65-rated enclosure, making it suitable for warehouses, factories, manufacturing facilities, parking structures, gymnasiums, retail spaces, and other commercial applications. The unit operates on 12V-24V DC power and provides a 0-10V dimming output with up to 30mA sinking current for reliable LED fixture control.
Two lens options are available to accommodate different mounting heights. The L7 lens is optimized for low bay installations with mounting heights up to 13ft, while the L8 lens is designed for high bay applications with mounting heights up to 40ft. Both versions offer a maximum detection radius of 23ft.
For additional flexibility, users can select adjustable time delays of 10 seconds, 1 minute, 5 minutes, or 15 minutes. The integrated daylight harvesting function allows light-level settings of 300 lux, 500 lux, 800 lux, or disable mode, helping maximize energy savings without compromising visibility.
The sensor is engineered for reliable performance in harsh conditions, supporting operating temperatures from -4°F to 140°F (-20°C to 60°C) and humidity levels up to 95% RH.
Whether upgrading a warehouse, factory, commercial building, or industrial facility, the Commercial Occupancy Sensor Daylight Harvesting 0-10V Dimming Control delivers intelligent lighting automation, improved energy efficiency, and dependable long-term performance.
