LED Troffer 2x4 72/60/50/40/30W - 30/35/40/50/65K Watt and CCT Tunable












                    SPECIFICATIONS:
SKU: T4G-EWF-7210J-SW





















LED Replacement for 2x4 Troffer













Electrical:






                                Watts:72



                                Operating Voltage:100-277 VAC



                                Operating Temperature: -22° F to 104° F



                                Operating Humidity:20% to 90%RH



                                Power Factor (PF):>98%



                                Power Supply Efficiency:>90%









Photometric:






                                LED Luminous Flux (lm):10151



                                Luminous Efficiency:141



                                CRI (ra):>80



                                Color Temperature (Kelvin):Tunable 3/3.5/4/5/6.5K



                                Lens type:Frosted



                                Expected Life: 70,000 hrs.



                                L70:50,000 hrs.



                                Beam Angle:150º









Mechanical:






                                IP Rating:IP64



                                Connector:Driver



                                Base Type: Hardwired



                                Heat Radiator:Anodized Aluminum



                                Color:Silver / Aluminum



                                Product Size:47.75" x 23.74" x 1.97"




                                Package Size:49'' x 2'' x 25''



                                Unit Gross Weight: 10.0000 Lb









Certifications:






                                Safety Compliance:



                                EMI/RFI compliance:FCC



                                Energy Efficiency/Performance:



                                Environmental:RhOS































APPLICATIONS:

And more








                615 N 21st Avenue, Hollywood, FL 33020, United States of America - Tel: +1 (844)533-7230

contact@ledradiant.com - www.ledradiant.com




Enhance Commercial Lighting Projects with the LED Troffer 2x4 Watt & CCT Tunable: The Smart, Flexible Solution for Modern Installations

For electrical contractors, choosing lighting that adapts to diverse project needs is essential. The LED Troffer 2x4 72/60/50/40/30W – 30/35/40/50/65K Watt and CCT Tunable is engineered to give you maximum control, offering a single fixture that delivers multiple performance levels. With tunable wattage, selectable color temperatures, and an impressive 10151 lumens, this troffer is designed to simplify installation while elevating lighting quality in every space.

Tunable Wattage for Ultimate Flexibility

Every project has different lighting demands, and this troffer meets them all with five selectable wattage options:
72W, 60W, 50W, 40W, and 30W.

This feature allows contractors to fine-tune brightness depending on the room, lighting design, code requirements, or client preferences. Whether your installation calls for high-output illumination in retail and industrial areas or lower wattage in offices and meeting rooms, this fixture adapts seamlessly. By replacing multiple SKUs with one tunable unit, contractors streamline inventory, reduce labor complexity, and ensure uniformity across large installations.

Selectable Color Temperatures

To match the unique ambiance of each environment, the LED Troffer 2x4 includes five CCT options — 3000K, 3500K, 4000K, 5000K, and 6500K.
This versatility makes it easy to design spaces with the right visual tone:

• Warm lighting (3000K–3500K) for hospitality, reception areas, and relaxed environments

• Neutral white (4000K) for classrooms, libraries, or collaborative workspaces

• Cooler daylight tones (5000K–6500K) for productivity-focused zones such as offices, clinics, labs, and retail

Different departments or rooms can share the same fixture model while maintaining lighting tailored to their needs.

High Lumen Output and Uniform Distribution

Delivering 10151 lumens, this troffer provides bright, even, and comfortable illumination suited for high-performance environments. Its advanced LED backlit technology ensures smooth distribution with minimal glare or shadows, enhancing visibility and reducing visual fatigue. The clean, modern aesthetic integrates well into suspended-ceiling systems, improving overall space design and user comfort.

Energy Efficient and Cost-Effective

Designed for long-term sustainability, the LED Troffer 2x4 combines adjustable wattage with high-output LED chips to maximize energy savings. Users benefit from reduced electricity bills, less heat emission, and lower maintenance over the fixture’s lifespan. The ability to tune wattage also allows future adjustments as usage patterns or lighting needs change—a valuable advantage in dynamic commercial spaces.

Simple Installation for Contractors

The lightweight 2x4 troffer fits seamlessly into standard ceiling grids and is engineered for fast, straightforward installation. Quick-connect wiring and durable construction reduce time on-site and minimize the risk of complications during retrofits or new-build projects.

Suited for Multiple Applications

This multipurpose fixture is ideal for:

• Offices and conference rooms

• Hospitals, clinics, and healthcare buildings

• Retail stores and showrooms

• Schools, universities, and training centers

• Government and corporate facilities

Its adaptable features ensure optimal lighting performance across a wide variety of commercial environments.

Built for Reliability

Each unit undergoes rigorous testing for performance, safety, and durability. Backed by strong manufacturer warranties and engineered for long-term operation, this troffer offers contractors confidence and clients consistent quality.

A Smarter Way to Light Modern Spaces

Combining wattage tunability, CCT adjustability, and a powerful 10151-lumen output, the LED Troffer 2x4 provides a future-ready lighting solution for professional installations. Versatile, efficient, and dependable, it’s the ideal choice for contractors seeking high-performance illumination with maximum flexibility.

We invite you to browse our selection and do not hesitate to chat with us or call us to 844-533-7230 for any question regarding our LED products.
