Exit Sign Edge-Lit Battery Backup Double Face Red












                    SPECIFICATIONS:
SKU: LEC-REG-2FABB-RD





















Exit Sign Damp Location













Electrical:






                                Watts:4



                                Operating Voltage:120-277 VAC



                                Operating Temperature: -22° F to 122° F



                                Operating Humidity:10% to 90%RH



                                Power Factor (PF):>98%



                                Power Supply Efficiency:>98%









Photometric:






                                LED Luminous Flux (lm):250



                                Luminous Efficiency:63



                                CRI (ra):>60



                                Color Temperature (Kelvin):Red



                                Lens type:None



                                Expected Life: 140,000 hrs.



                                L70:100,000 hrs.



                                Beam Angle:160º









Mechanical:






                                IP Rating:IP65



                                Connector:Wired



                                Base Type: Hardwired



                                Heat Radiator:Anodized Aluminum



                                Color:Red (light)



                                Product Size:10.47" x 13.7" x 1.81"




                                Package Size:12'' x 14'' x 3''



                                Unit Gross Weight: 36.0000 Lb









Certifications:






                                Safety Compliance:



                                EMI/RFI compliance:FCC



                                Energy Efficiency/Performance:



                                Environmental:RhOS































APPLICATIONS:

And more








                615 N 21st Avenue
, Hollywood, FL 33020
, United States of America - Tel: +1 (844)533-7230

contact@ledradiant.com - www.ledradiant.com




Exit Sign Edge-Lit Battery Backup Double Face Red

The Exit Sign Edge-Lit Battery Backup Double Face Red is a reliable and modern emergency lighting solution designed to provide clear, highly visible exit guidance in a wide range of commercial and public environments. Featuring advanced LED edge-lit technology and a sleek double-face design, this exit sign ensures occupants can safely and quickly locate exits during power outages or emergency situations.

Engineered for dependable performance, this exit sign includes a 90-minute battery backup, delivering continuous illumination when normal power is interrupted. The long-lasting battery system is supported by a built-in test switch and charge rate indicator, allowing for easy maintenance checks and ensuring the fixture remains fully operational at all times. Its efficient LED illumination provides bright, uniform light while minimizing energy consumption and reducing long-term operating costs.

This edge-lit exit sign meets strict safety and performance standards, complying with UL 924, NEC, OSHA, and NFPA 101 Life Safety Code requirements. These certifications make it a trusted solution for projects where code compliance and occupant safety are top priorities. Additionally, the fixture is rated for damp locations, making it suitable for installation in areas where moisture or humidity may be present without compromising reliability.

Designed for maximum installation flexibility, the Exit Sign Edge-Lit Battery Backup Double Face Red supports multiple mounting configurations. It can be installed on walls, standard ceilings, high ceilings, sloped ceilings, or recessed applications, allowing it to adapt easily to different building layouts and architectural requirements. This versatility makes it one of the most adaptable exit signs available on the market today.

The fixture features premium construction, combining a durable aluminum housing with a high-grade acrylic face. This combination not only ensures long-term durability but also delivers a clean, professional appearance suitable for modern interiors. The double-face design improves visibility from multiple directions, making it ideal for corridors, open spaces, and central mounting locations.

For added customization, the exit sign includes field-installable directional arrows that can be configured for left, right, or both directions. This allows installers to tailor the signage to specific egress paths without the need for additional components. The unit also supports dual voltage operation (120V / 277V), simplifying integration into various electrical systems.

While this model is non-CEC compliant, it remains an excellent choice for applications where CEC certification is not required and high performance, durability, and ease of installation are essential.

Ideal applications include commercial buildings, retail spaces, educational institutions, healthcare facilities, and public buildings such as libraries and government offices. Wherever clear exit identification is critical, the Exit Sign Edge-Lit Battery Backup Double Face Red delivers dependable performance, modern design, and peace of mind—making it a smart investment in safety and compliance.
