Upgrade Your Outdoor Lighting with Our 25W LED Mini Wall Pack
Efficient Illumination
Illuminate your outdoor spaces with our 25W LED Mini Wall Pack, which provides exceptional brightness equivalent to a 120W HID bulb. With 2700 lumens of light output, this wall pack ensures optimal visibility and safety.
Energy-Saving Solution
Our LED Mini Wall Pack comes with photocell control, allowing it to turn on at dusk and off at dawn automatically. This feature saves over 75% in electricity costs and eliminates the need for frequent bulb replacements, resulting in significant long-term savings.
Durable and Long-Lasting
Built to withstand outdoor conditions, our Wall Pack is IP65 waterproof rated, ensuring reliable performance even in harsh weather environments. With a lifespan of over 15 years, it offers durability and longevity, reducing maintenance hassles.
Versatile Applications
Ideal for various outdoor lighting applications, our LED Mini Wall Pack is suitable for illuminating building exteriors, parking lots, walkways, and more. Its compact size and easy installation make it a versatile lighting solution for contractors and electricians.
High ROI
With an estimated annual ROI of about 60%, our LED Mini Wall Pack offers a cost-effective lighting solution for commercial and residential properties. Experience superior efficiency and reliability with LEDRADIANT Wall Packs.
We invite you to browse our selection and do not hesitate to chat with us or call us to 844-533-7230 for any question regarding our LED products.
| NONE |
MEDIUM WALL PACK INSTALLATION GUIDE
(WTM-TZP-70600-4Y/5Y)
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
1. To avoid electric shock, disconnect power at source prior to installation.
1. Junction box Mounting
1. Loosen screws and remove the front lens set carefully from the back plate.
2. Drill appropriate knockouts (B) for wiring, the fixture supports standard 3 1/4' and 4" Junction box.
3. Attach the back plate on the wall use the supplied gaskets for a weather tight seal
4. Finish wiring (Black for Line, White for Neutral and Green/Yellow wire for Ground).
5. Replace the lens on the hinges, make connections and close the lens set then tighten the screws.
2. Conduit Mounting
1. Loosen screws and remove the front lens set carefully from the back plate.(See step 1 above)
2. Remove 1/2 'plug from where you intend to feed conduit
3. Drilling out the holes (C) to secure it on the wall with choosing proper screws.
4. Finish wiring (Black for line, White for neutral and Green/Yellow for ground). (See step 4 above)
5. Replace the lens on the hinges, make connections and close the lens set and tighten the screws to fasten the lens set to the back plate.
Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com – www.ledradiant.com
5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures
• This warranty policy is valid only for products sold in The United States of America.
• Products have been purchased directly from a LEDRadiant (sales) organization. • Proof of purchase is available for inspection by LEDRadiant. • Products have been properly installed and operated in accordance with the manufacturer’s instructions. • More than 10% of the LED chips are not properly working. • A LEDRadiant representative will have access to the defective Products. • If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems. • Shipping and Labor costs for installation of the Products are not covered under this warranty. This warranty is valid for order number: By LEDRadiant
Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com – www.ledradiant.com |
Customer Reviews
- Great value for the money Review by Samantha
-
Rate Great value for the money! The 25W LED Mini Wall Packs provide just the right amount of brightness with a warm, inviting glow. I installed them around my house’s facade, and they’ve really enhanced the building’s perimeter. They add a lovely touch of light and security. I’ll definitely be buying more!(Posted on 6/27/2024) - awesome Review by Chris
-
Rate ust got the 25W LED Mini Wall Pack with photocell, and it's fantastic! It's incredible how it equals a 120W HID bulb while saving so much energy and money on replacements. Plus, with its waterproof design and long lifespan, it's a reliable choice for outdoor lighting. Highly recommend for anyone looking to upgrade!(Posted on 3/31/2024) - The Mini Wall Pack W/photocell is spectacular Review by Eddi S
-
Rate The costumer love the Mini Wall Pack the brightness and that is W/photocell.(Posted on 12/29/2022) - Good quality product Review by Zack J
-
Rate Well built, bright. Fast shipping.(Posted on 10/5/2020)
- Product Description
-
Upgrade Your Outdoor Lighting with Our 25W LED Mini Wall Pack
Efficient Illumination
Illuminate your outdoor spaces with our 25W LED Mini Wall Pack, which provides exceptional brightness equivalent to a 120W HID bulb. With 2700 lumens of light output, this wall pack ensures optimal visibility and safety.
Energy-Saving Solution
Our LED Mini Wall Pack comes with photocell control, allowing it to turn on at dusk and off at dawn automatically. This feature saves over 75% in electricity costs and eliminates the need for frequent bulb replacements, resulting in significant long-term savings.
Durable and Long-Lasting
Built to withstand outdoor conditions, our Wall Pack is IP65 waterproof rated, ensuring reliable performance even in harsh weather environments. With a lifespan of over 15 years, it offers durability and longevity, reducing maintenance hassles.
Versatile Applications
Ideal for various outdoor lighting applications, our LED Mini Wall Pack is suitable for illuminating building exteriors, parking lots, walkways, and more. Its compact size and easy installation make it a versatile lighting solution for contractors and electricians.
High ROI
With an estimated annual ROI of about 60%, our LED Mini Wall Pack offers a cost-effective lighting solution for commercial and residential properties. Experience superior efficiency and reliability with LEDRADIANT Wall Packs.
We invite you to browse our selection and do not hesitate to chat with us or call us to 844-533-7230 for any question regarding our LED products.
- Additional Information
-
NONE
MEDIUM WALL PACK INSTALLATION GUIDE(WTM-TZP-70600-4Y/5Y)PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
1. To avoid electric shock, disconnect power at source prior to installation.
2. The installation should be performed by qualified electricians or lighting technicians.
3. Before conducing any installation, maintenance, or removal, disable all power to the luminaries and wait until the fixture cool down.
4. Do not touch the fixture while it is in service.
5. If there is any problem with the fixture, DO turn off power, and DO NOT attempt repair unless you are a qualified technician or the customer service member.
1. Junction box Mounting
1. Loosen screws and remove the front lens set carefully from the back plate.
2. Drill appropriate knockouts (B) for wiring, the fixture supports standard 3 1/4' and 4" Junction box.
3. Attach the back plate on the wall use the supplied gaskets for a weather tight seal
4. Finish wiring (Black for Line, White for Neutral and Green/Yellow wire for Ground).
5. Replace the lens on the hinges, make connections and close the lens set then tighten the screws.
2. Conduit Mounting
1. Loosen screws and remove the front lens set carefully from the back plate.(See step 1 above)
2. Remove 1/2 'plug from where you intend to feed conduit
3. Drilling out the holes (C) to secure it on the wall with choosing proper screws.
4. Finish wiring (Black for line, White for neutral and Green/Yellow for ground). (See step 4 above)
5. Replace the lens on the hinges, make connections and close the lens set and tighten the screws to fasten the lens set to the back plate.
Save the environment, your children and the planet500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com – www.ledradiant.com
5 YEAR WARRANTY POLICYFor Commercial LED Lamps and fixtures
This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps .
This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned.
This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) .
This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale.
Warranty period
5 Year. The warranty period starts on the date the products are delivered.
By default, purchaser receives above mentioned ‘standard warranty’.
On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order.
Purchaser shall not rely upon any other information or documentation.
Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better.
Summary Warranty Terms and Conditions (non-exhaustive)
• This warranty policy is valid only for products sold in The United States of America.
• Products have been purchased directly from a LEDRadiant (sales) organization.
• Proof of purchase is available for inspection by LEDRadiant.
• Products have been properly installed and operated in accordance with the manufacturer’s instructions.
• More than 10% of the LED chips are not properly working.
• A LEDRadiant representative will have access to the defective Products.
• If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems.
• Shipping and Labor costs for installation of the Products are not covered under this warranty.
This warranty is valid for order number:
By LEDRadiant
Save the environment, your children and the planet500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com – www.ledradiant.com - Product Tags
- Reviews
-
Customer Reviews
- Great value for the money Review by Samantha
-
Rate Great value for the money! The 25W LED Mini Wall Packs provide just the right amount of brightness with a warm, inviting glow. I installed them around my house’s facade, and they’ve really enhanced the building’s perimeter. They add a lovely touch of light and security. I’ll definitely be buying more!(Posted on 6/27/2024) - awesome Review by Chris
-
Rate ust got the 25W LED Mini Wall Pack with photocell, and it's fantastic! It's incredible how it equals a 120W HID bulb while saving so much energy and money on replacements. Plus, with its waterproof design and long lifespan, it's a reliable choice for outdoor lighting. Highly recommend for anyone looking to upgrade!(Posted on 3/31/2024) - The Mini Wall Pack W/photocell is spectacular Review by Eddi S
-
Rate The costumer love the Mini Wall Pack the brightness and that is W/photocell.(Posted on 12/29/2022) - Good quality product Review by Zack J
-
Rate Well built, bright. Fast shipping.(Posted on 10/5/2020)
